Know Your Limit: Do not exceed the 1,000 lb operating capacity of the VM1000. Attempting to lift heavy pallets of sod, pavers, or rock can cause the rear of the machine to lift off the ground.
The "Low & Slow" Rule: Travel with the load as low to the ground as possible (no more than 6–10 inches).
Tip-Over Hazard: Never turn the machine or drive across a slope with the forks raised. This drastically shifts the center of gravity and can cause a rollover.
Safety First: If the load feels unstable or the back tracks start to lift, lower the load immediately. For assistance, call (435) 708-1927.
Proper Operation
Adjusting Fork Width: Pull the locking pins on top of each fork.
Leveling the Load: Approach the pallet straight-on.
Driving on Inclines:
Going Uphill: Drive forward (load in front).
Going Downhill: Drive in reverse (load stays on the uphill side). Never point the forks downhill while carrying a load.
Pro-Tips for Renters
Avoid "Tip Loading": Always push the forks all the way into the pallet until the backrest touches the load. Lifting from the tips of the forks reduces your lifting capacity by 50% or more.
Visibility: If a tall load blocks your view while driving forward, travel in reverse and look over your shoulder. Do not "guess" what is in front of you.
Surface Awareness: Be careful on soft Cedar City dirt or mud. A heavy load on narrow forks puts immense pressure on the front tracks, which can cause the machine to sink or get stuck.
Inspection & Return
Check for Bends: Inspect the forks for any visible bending or cracks in the "heel" (the 90-degree bend).
Locking Pins: Ensure the sliding mechanism is free of rocks and debris so the pins can lock properly.
Clean the Frame: Please hose off any mud or concrete splatter from the carriage frame before returning.
